3D geomat erosion control geomat for soil consolidation
Product Features
Three-dimensional geonet (3D geonet) with slope protection technology, because 3D geonet can significantly improve the overall and local stability of the slope, and can be conducive to the growth of slope vegetation, has been widely used in highway slope engineering in recent years. However, due to the close connection of construction projects, steep slope, high slope, weathered fossil slope and other characteristics, and in order to catch up with the construction period, it is necessary to construct in the summer high temperature season. In the construction practice, there are some phenomena such as grass coverage and low survival rate. Therefore, our company's three-dimensional geonet cushion has always advocated the standardization of construction technology, pay attention to scientific construction is very necessary. Three-dimensional geonet (3D geonet) can greatly reduce the cost of construction, simple construction and easy operation. Because of the use of macromolecule materials, it has good chemical stability and no pollution to the environment.
Product Parameters
| Specifications |
EM2 |
EM3 |
EM4 |
EM5 |
| Unit area gram weight(g/m2) (kN) ≥ |
220 |
260 |
350 |
430 |
| thickness(mm) ≥ |
10 |
12 |
14 |
16 |
| Longitudinal Tensile Strength(kN) ≥ |
0.8 |
1.4 |
2.0 |
3.2 |
| Transverse Tensile Strength(kN) ≥ |
0.8 |
1.4 |
2.0 |
3.2 |
Application and After-Sales Service
1. Prevent subgrade cracks and collapses.
2. Enhance the foundation, dam slope, improve the stability of roadbed, reduce the area occupied;
3. It can bear heavy load.
4. Shorten the construction period; Geotechnical network specifications and performance parameters can also be constructed under harsh environmental conditions.
5. It can be used to strengthen the pavement and integrate the grid with the pavement material. It can effectively disperse the load and prevent the pavement cracks.
6. The seashore and waterway projects have strong flexibility, good permeability, are not eroded by sea water, and can absorb wave impact.
7.Geotechnical network can be made into rectangular, square or tubular stone cages directly installed underwater.
